Main functions and features:

1. Adopt 2.0-inch black and white screen, wide illumination, wide working range

2. It can store 10 test results and test records 5 test units to choose from

3. Two language options Chinese English Low power alarm

4. Warm-up time: 10S Response time: 5S

5. Measuring range: 0~0.400 g/l, 0~4.000 ‰BAC, 0~0.400 %BAC, 0~2.000 mg/l, 0~440 mg/100ml, indication error: ±0.020mg/

6. Alarm point: 0.02 0.03 0.05 0.08%

7. Using 2.0-inch dot matrix black and white screen, suitable for wide illumination and wide operating temperature range.

Alarm point settings

1 This operation sets the threshold value of drinking and drunkenness alarm.

2 Press the left button to select [Alarm Point], press the right button to confirm, and enter the drinking and drunkenness setting interface. At this time, press the left button to select the drinking alarm point 20 30 50 80, and press the right button to confirm after selection.

Press the left button again to adjust the drunken alarm point 20 30 50 80, press the right button to confirm and return to the setting interface.

3 After the unit change, the threshold value of drinking and drunk driving in the "Alarm Settings" will be automatically updated according to the conversion relationship between the new and old units.

Unit settings

1) Press the left button to select [Units] and right-click to confirm the units.

2) Press the left button to select the unit used this time, press the right button to confirm the unit and return to the setting interface.

3) This machine provides 5 kinds of units for users to choose:

Blood alcohol concentration g/l ( 4.000)

Blood alcohol concentration ‰ BAC ( 4.000)

Blood alcohol concentration % BAC ( 0.400)

Breath alcohol concentration mg/l ( 2.000 )

Blood alcohol concentration mg/100ml ( 440 )

Product Specifications:

1. Product size: 125x68x24mm

2. Color box size: 145x110x45mm

3. Carton size: 46×26×31cm

4. Packing quantity: 40PCS

5. Product net weight: 150g

6. Product gross weight: 228g

7. Packing gross weight: 9.7kg
